The Sieve Shaker OCTAGON 200 is a high-performance benchtop laboratory sieve shaker designed for accurate particle size analysis. Manufactured to meet international laboratory standards by Endecotts, this model delivers reliable and repeatable results using advanced electromagnetic 3D sieving motion.
It is suitable for both dry and wet sieving applications and supports large batch capacities of up to 3 kg. The digital timer, adjustable amplitude, and quick-release clamping system make operation simple, efficient, and precise. Ideal for quality control, research laboratories, and industrial testing environments.
Key Features
-
Electromagnetic 3D sieving motion
-
Digital time display
-
Adjustable amplitude control
-
Supports dry and wet sieving
-
Quick-release clamping system
Specifications
-
Range: 20 µm to 125 mm
-
Max. batch capacity: 3 kg
-
Max. sieves: 8 full height / 16 half height
-
Speed: 3,000 min-1 (50 Hz)
-
Sieve diameter: 100 / 200 mm (8”)
-
Max. stack height: up to 450 mm
-
Protection class: IP21
-
Power supply: Single phase (various voltages)
-
Dimensions: 418 × 232 × 435 mm
-
Net weight: Approx. 35 kg
-
Model type: Benchtop
